55" Outdoor Commercial Signage
Sorry, this product is no longer available, please contact us for a replacement.
Click here to jump to more pricing!
Outstanding Visiblity with High Reliability
The XE series provides the optimal solution to satisfy the high demand for accurate information. With superior picture quality and excellent durability, this outdoor display delivers eye-catching content to captivate customers even under direct sunlight or extreme changes in the environment.
- Size: 55"
- Brightness: 3,000 cd/m2 (Typ.)
- Life Time: 50,000 hours
- Operation Temperature: -22°F to 122°F / -30°C to 50°C
- IP56 Design
- Interface: HDMI, DP, DVI-D, USB 3.0, SD Card, External Speaker, RS232C, RJ45
With a powerful brightness of 3,000 cd/m2 and wide viewing angles, the XE series delivers content clearly and catches the attention of viewers no matter where they are, making it the ultimate display for outdoor visibility.
Visible with Polarized Sunglasses
QWP* technology enables clear visibility even when the viewer is wearing polarized sunglasses.
Smart Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in daylight for better visibility, and it is decreased in darker environments for efficient power management.
Even under direct sunlight exposure, the open frame XE series remains free from blackening defects in temperatures below 230°F / 110°C, providing superior quality for outdoor usage.
Secured Protection with IP56 Design
The XE series is sealed with IP56 rated design for reliable operation. It’s designed to be not only water resistant but also resistant against the damaging effects of the sun, rain, snow, dust and wind, an essential feature for outdoor application.
The product can be often unavoidably exposed to dust and water during maintenance. Conformal coating on every major circuit board protects against dust, iron powder, humidity, etc.
An electrical circuit breaker and surge suppressor are integrated inside ensuring absolute protection from overcurrent short circuits, and unwanted voltages. This helps prevent equipment damage and safety hazards in the future.
Tempered and laminated front glass ensures protection, from outdoor extremities allowing minimal damage from external impacts.
Wide Range of Operating Temperatures
The panel offers superb reliablity under a wide range of operating temperatures, so the XE series requires fewer constraints for outdoor installation.
Enhanced Thermal Management
The patented thermal management technology efficiently cools down the heat generated from every part of the product, preventing outside air from entering.
Replaceable Front Glass
In case of outdoor accidents or vandalism, the protective glass of 49XEB3E can be detached from its main body which allows for an instant replacement on site.
The LG Control Manager is an embedded web monitoring program that allows a variety of parameters to be diagnosed in real time such as temperature, pixel status, door status, ambient light, filter*, and gyro sensors. The LG Control Manager can be easily monitored at all times.
Optional stand accessories are provided to allowthe panelto stand freely on the ground and facilitate easy cable management. For the 49XEB3E there is an exclusive stand for 1x3 configuration available to meet various business requirements.
|Screen Size||55” Class (54.64” Diagonal)|
|Aspect Ratio||16 : 9|
|Native Resolution||1920 x 1080 (FHD), M+ (WRGB)|
|Brightness||3,000 cd/m2 (Typ.), 2,400 cd/m2 (Min.)|
|Viewing Angle (H x V)||178 x 178|
|Response Time||9 ms (G to G BW, Typ.)|
|Surface Treatment||Hard Coating (2H), Anti-reflection Treatment of the Front Polarizer (Haze 3% (Typ.)), QWP|
|Operating Hour||24 Hours|
|Orientation||Landscape & Portrait|
|Input||HDMI, DP, DVI-D, Audio In, USB 3.0, SD Card|
|Output||DP, External Speaker Out|
|External Control||RS232C In/out, RJ45 In|
|Front glass||7.5 mm (AR, Tempered & Laminated Glass)|
|Bezel Width||66.4 mm (T/B), 31.0 mm (L/R)|
|Monitor Dimension (W x H x D)||745.3 x 1,345.4 x 160.0 mm / 29.3” x 53.0” x 6.3”|
|Weight (Head)||70kg / 154.3 lbs|
|Monitor with Optional Stand Dimensions (W x H x D)||745.3 x 1,877 x 420 mm / 29.3” x 73.9” x 16.5”|
|Weight (Head+Stand)||103.5kg / 228.2 lbs|
|Packing Dimensions (W x H x D)||1,027 x 1,491 x 309 mm / 40.4” x 58.7” x 12.2|
|Packed Weight||100.5kg / 221.6 lbs|
|Special Features||Temperature Sensor, Auto Brightness Sensor, Pixel Sensor, Cooling FAN, ISM Method, DPM Select, Energy Saving, Smart Energy Saving, File Play with USB, Internal Memory 8GB (System 4GB + Available 4GB), USB Cloning, Easy Brightness Control, Wake on LAN, Fail Over, DP Daisy Chain, Control Manager|
|Operating Temperature||-22°F to 122°F / -30°C to 50°C|
|Operating Humidity||5% to 100%|
|Dust / Water Proofing||IP56|
|Power Supply||100-240V~, 50/60Hz|
|Power Type||Built-In Power|
|Power Consumption - Typ. / Max||350 W / 500 W|
|Power Consumption - Smart Enegy Saving||178 W|
|Safety||UL / cUL / CB|
|EMC||FCC Class "A" / CE / KCC|
|Content Management Software||SuperSign CMS|
|Control and Monitoring Software||SuperSign C|
|Basic||Remote Controller, Manual (EIG, ESG), Regulation Book, Phone to RS232C Gender, USB Cable, HDMI Cable|
|Optional||Enclosure Stand (ST-550X)|
|Warranty||3-Year Limited Warranty (Parts and Labor) | Extended Warranties Available|
Download the LG Outdoor Commercial Signage - XE Series Datasheet (.PDF)
